Tesla Gen 3 Level 2 EV Home Charger

The most practical charging solution for houses, apartments and workplaces. Multiple power settings, up to 44 miles of range added per hour of charging. Charge at home, anytime and get a full charge overnight. With customized power settings, a lightweight design perfect for indoor or outdoor use, including a range of electrical systems and mounting options. Monitor your charge with the Tesla app and receive notifications when it’s complete. Wi-Fi connectivity enables remote service if necessary. Lightweight 18′ cable length.

  • Up to 44 miles of range per hour of charge
  • Compatible with Model S, Model 3, Model X and Model Y
  • Up to 11.5 kW / 48 amp output
  • Customizable power levels on a range of circuit breakers
  • Compatible with any home electrical system
  • Compatible for power sharing with other Gen 3 Wall Connectors only
  • Wi-Fi connectivity (2.4 GHz 802.11 b/g/n)
  • Approved for indoor and outdoor installation
  • Lightweight 8.5″, 18’ or 24″ cable lengths Tempered white glass faceplate

AC Voltage (Nominal): 120/240 V
Feed-In Type: Split Phase
Grid Frequency: 60 Hz
Total Energy: 14 kWh
Usable Energy: 13.5 kWh
Real Power, max continuous: 5 kW (charge and discharge)
Real Power, peak (10 s, off-grid/backup): 7 kW (charge and discharge)
Apparent Power, max continuous: 5.8 kVA (charge and discharge)
Apparent Power, peak (10 s, off-grid/backup): 7.2 kVA (charge and discharge)
Maximum Supply Fault Current: 10 kA
Maximum Output Fault Current: 32 A
Overcurrent Protection Device: 30 A
Imbalance for Split-Phase Loads: 100%
Power Factor Output Range: +/– 1.0 adjustable
Power Factor Range (full-rated power): +/– 0.85
Internal Battery DC Voltage: 50 V
Round Trip Efficiency: 90%
Warranty:
10 years

Dimensions: 1150 mm x 755 mm x 147 mm (45.3 in x 29.6 in x 5.75 in)
Weight: 114 kg (251.3 lbs)
Mounting options: Floor or wall mount

Dimensions and weight differ slightly if manufactured before March 2019.

Operating Temperature: –20°C to 50°C (–4°F to 122°F)
Recommended Temperature: 0°C to 30°C (32°F to 86°F)
Operating Humidity (RH): Up to 100%, condensing
Storage Conditions: –20°C to 30°C (–4°F to 86°F) | Up to 95% RH, non-condensing | State of Energy (SoE): 25% initial
Maximum Elevation: 3000 m (9843 ft)
Environment: Indoor and outdoor rated
Enclosure Type: NEMA 3R
Ingress Rating: IP67 (Battery & Power Electronics) | IP56 (Wiring Compartment)
Wet Location Rating: Yes
Noise Level: @1m: <40 dBA at 30°C (86°F)

Certifications: UL 1642, UL 1741, UL 1973, UL 9540, IEEE 1547, UN 38.3
Grid Connection: Worldwide Compatibility
Emissions: FCC Part 15 Class B, ICES 003
Environmental: RoHS Directive 2011/65/EU
Seismic: AC156, IEEE 693-2005 (high)
